DIBOND® is an aluminium composite sheet from the house of 3A Composites. With 0.25 mm thick aluminium cover skins and a polyethylene core, it is lightweight, rigid yet formable.

3A Composites continually enhances the DIBOND® product portfolio. Emphasizing more than just aesthetic appeal, these panels are also designed to meet functionality ensuring the product stands out in design as well as performance.

DIBOND® Brochure

Download our new DIBOND® Brochure as PDF file.

Download as PDF



CHARACTERISTICS

  • Aluminium cover skins AA3105 series with H24 Temper as per EN 485
  • Resistance to weathering & corrosion
  • Panel thickness: 3mm (0.25mm) and 4mm (0.25mm)
  • Core: Polyethylene
    FR available on request (MOQ applicable)
  • Coating: Ultra Durable Coating
  • Panel length: 2440mm, 3050mm and 3660mm (can be customized)
  • Width: 1220mm ± 2mm
  • Warranty: 10 Years

APPLICATIONS

  • Interior design | Partition | Furniture
  • Signage I Lettering I Kiosk I Lighting boxes
  • Displays (POS/POP)
  • Corporate Identity
  • Shop design I Shop window decoration
  • Exterior wall cladding and many more

PROCESSING

  • Digital printing*
  • Screen printing*
  • Laminating
  • Contour milling
  • Water jet cutting
  • Gluing
  • Shearing I Sawing I Punching
  • Drilling I Riveting | Screwing
  • Folding (V-groove)
  • Roll bending

*Special surface coating required. MOQ applicable

American Swiss Shopping Mall

Messebau Euroshop

Marcs Clothing Store

RADIATING STYLE WITH METALLIC COLOURS

DIBOND® metallics embrace a radiant charm that bestows your creativity with a touch of timeless elegance. These selected shades have gone through extensive testing to stand out in the design world.

Quartz Grey Metallic | D-201
Sparkling Silver Metallic | D-202
Lunar Silver Metallic | D-203
Lava Grey Metallic | D-204
Mercury Grey Metallic | D-205
Ice Blue Metallic | D-206
Oyster Gold Metallic | D-207
Satin Gold Metallic | D-208
Spark Copper Metallic | D-209
Ivory Bronze Metallic | D-210

TRANSFORMING STYLE WITH SOLID COLOURS.

DIBOND® solids embody timeless and refined elegance, adding a sense of grace and sophistication to your masterpieces. These chosen shades leave a lasting impression on the beholder.

Blanco White | D-301
Artic White | D-302
Dove White | D-303
Luminiuos Yellow | D-304
Fern Green | D-305
True Blue | D-306
Blueberry Blue | D-307
Carbon Black | D-308
Scarlet Red | D-309
Blazing Orange | D-310
Red Wine | D-311
Arsenic Grey | D-312
Grizzle Grey | D-313

REFLECTING STYLE WITH GLOSSY COLOURS.

DIBOND® glossy breathes life into your design vision with captivating vibrancy, infusing it with a modern, high-impact aesthetic that speaks to the heart. These handpicked shades are a shining example of visual appeal and craft

Glossy White | D-401
Glossy Red | D-402
Glossy Black | D-403

GENERAL INFORMATION

For exact colour matching, request for actual colour samples. Organic coatings are subject to batch-to-batch variation

CLEANING & MAINTENANCE

Annual cleaning is recommended. The surfaces should be cleaned either manually using a soft brush or by means of a high-pressure cleaner (maximum 50 bar) with clean water. If necessary, a mild cleaning agent (pH 6-7) may be added up to a maximum of 10%. Cleaning should take place from top to bottom. After cleaning, rinse with clean water to remove any cleaning agent residue. Do not clean surfaces heated by the sun (>40°C).

Do not use highly alkaline cleaning agents such as potassium hydroxide, sodium carbonate, caustic soda, any strong acid products or highly abrasive cleaning agents such as household cleaning products that can corrode the paint.

STORAGE & TRANSPORTATION

To protect DIBOND® panels against mechanical damages and harmful effects of weather the following should be observed:

  • Ensure careful handling of pallets during transport and unloading.
  • Examine the pallets throughly upon arrival for any damages due to transportation.
  • Stack only three pallets of similar dimensions horizontally above one another with the heaviest at the bottom. Do not let the panels stand vertically
  • Protect DIBOND® panels during storage against rain, penetration of moisture and condensation.
  • Only panels of identical size should be stacked, with a maximum of 6 panels stacked on top of each other.
  • Storage exceeding 6 months should be avoided, as it may become difficult to remove the protective foil.
  • When stacking the panels nothing should be placed in between them, as this could produce marks on the panels.

RECYCLING

DIBOND® can be fully recycled, i.e. both the core material and the aluminium cover sheets can be recycled and used for the production of new material.
